JA-115E-AN Jablotron 100+ Bus Four-Segment Keypad with Display and RFID – Anthracite
- Brand::Jablotron
- Product Code: JA-115E-AN
- Availability: In Stock
| Type of control device | B |
|---|---|
| Power | from control panel bus 12 V DC (8�15 V) |
| Current consumption in standby mode | 18 mA |
| Current consumption for cable selection | 150 mA |
| RFID frequency | 125 kHz |
| Maximum RFID magnetic field strength | -5.4 dB?A/m (measured at 10 m) |
| Dimensions | 110 x 136 x 33 mm |
| Weight | 285 g |
| Classification | Security grade 2/Environmental class II according to EN 50131-1 |
| Environment | indoor general |
| Operating temperature range | -10 �C to +40 �C |
| Average operational humidity | 75% RH, w/o condensation |
| Certification body | Trezor Test s.r.o. (nr. 3025) |
| In compliance with | ETSI EN 300 330, EN 50130-4, EN 55032, EN IEC 62368-1, EN IEC 63000, EN 50131-1, EN 50131-3 |
| Can be operated according to | ERC REC 70-03 |
| Recommended screw | 4 x � 3.5 x 40 mm (half-round head) |
The JA-115E-AN integrates four control segments, an LCD display and a 125 kHz RFID reader in one anthracite unit, so there is no separate segment assembly. Segment labels appear on the display, and the keypad shows the current system status at a glance.
Highlights
- Four fixed control segments with labels shown on the LCD
- 125 kHz RFID reader
- Bus powered (8–15 V DC)
- Security Grade 2 / Environmental Class II (EN 50131-1)
- Compatible with JA-102K, JA-103K and JA-107K panels
Where it suits
A tidy all-in-one keypad for residential and small commercial installations.
Installation and set-up
Connect it to the wired Jablotron 100+ bus, enrol it and set its behaviour in F-Link. We recommend installation by a Jablotron-trained installer; the installation manual is available in the Downloads tab.
