JB-EXT-TH-B Jablotron 100+ Bus Outdoor Thermometer
- Brand::Jablotron
- Product Code: JB-EXT-TH-B
- Availability: In Stock
| Operating temperature | -25 �C to +60 �C |
|---|---|
| Operating humidity | 0 % - 100 % |
| Power Supply | from the bus, 12 V (8 � 36V) |
| Internal sensor temperature measurement range accuracy | �0.6 �C |
| External sensor temperature measurement range accuracy | �1 �C |
| Dimensions | 90 x 110 x 35 mm |
| Measured temperature range for the internal temperature sensor | -25 �C to +60 �C |
| Measured temperature range for the external temperature sensor | -50 �C to +200 �C |
| Ingress protection class | IP 53 |
The JB-EXT-TH-B measures temperature outdoors and sends readings to the panel and the cloud, where you can set high and low limits with SMS or email notification. A JB-TS-PT1000 probe can be added for liquids, air or closed containers.
Highlights
- Operating range –25 to +60 °C
- Internal sensor accuracy ±0.6 °C
- Optional external probe (±1 °C)
- 90 × 110 × 35 mm
Where it suits
Suits farms, pools, tanks and cool storage.
Installation and set-up
Connect it to the wired Jablotron 100+ bus, enrol it and set its behaviour in F-Link. We recommend installation by a Jablotron-trained installer; the installation manual is available in the Downloads tab.
Tags: JB-EXT-TH-B, outdoor thermometer, temperature sensor, Jablotron 100+, bus
